| voltage | DC5~24V |
| Magnetic detection direction | forward |
| Maximum detection distance | Square iron plate 30×10t | 6mm |
| Square iron plate 30×2t | 4mm |
| output method | LSPSF002: |
| NPN normally open (ON during operation) ※1 |
| LSPSF002(B)： |
| NPN Normally closed (OFF during operation) ※1 |
| Output current | 15mA MAX ※1 |
| Current consumption | 8mAMAX |
| Withstand voltage | AC1000V |
| 1 minute, between the entire charging part and the casing |
| Insulation resistance | DC250V |
| 20MΩ or more, between the entire charging part and the casing |
| Working temperature |
|
| Working environment humidity | 20~80%RH |
| Wire specifications | φ2.8×1000mm※1 |
| LSPSF002: gray |
| LSPSF002(B): black |
| shell material | Fiberglass reinforced resin: Black/ Metal fittings: Brass |
| Install | M3 screws, tightening torque 0.3N·m |
| indicator light | red |
※1 Output conversion, current amplification, and cable extension can be achieved through wire accessories. Please refer to P.127 ~ 130 for details.
