voltage	DC5~24V
Magnetic detection direction	up
Maximum detection distance	Iron wireφ2	1mm
	Square iron plate 30×1t	2mm
output method	LSPSF001:
	NPN normally open (ON during operation)		※1
	LSPSF001(B)：
	NPN normally closed (OFF during action)			※1
Output current	LSPSF001	15mAMAX※1
	LSPSF001(B)
	LSPSF001-LED	15mAMAX
	LSPSF001(B)-LED
Current consumption	LSPSF001	8mA MAX ※1
	LSPSF001(B)
	LSPSF001-LED	8mAMAX
	LSPSF001(B)-LED
Withstand voltage	AC1000V (1 minute, between the entire charging part and the casing)
Insulation resistance	DC250V
	20MΩ or more, between the entire charging part and the casing
Working temperature	- 20℃~ +85℃ (no condensation)
Working environment humidity	20~80%RH
Wire specifications	φ2.8×1000mm※1
	LSPSF001/LSSPF001-LED: gray
	LSPSF001(B)/LSPSF001(B)- LED: Black
shell material	Heat-resistant ABS resin/SUS304
indicator light	LSPSF001	none
	LSPSF001(B)
	LSPSF001-LED	distance sensor
		Main body about 100mm		※2
	LSPSF001(B)-LED

※1 Output conversion, current amplification, and cable extension can be achieved through wire accessories. For details, please refer to P.127 ~ 130

※2 Please see P127 for confirmation of indicator light size.
