voltage	DC5～24V
Magnetic detection direction	forward
Maximum detection distance	Iron 10×10×1t 2.3mm
output method	LSPSF014:
	NPN normally open (ON during action) ※ 1
	LSPSF014(B):
	NPN normally closed (OFF during action) ※ 1
Output current	15mAMAX1
Current consumption	8mAMAX
Withstand voltage	AC1000V
	1 minute, between the entire charging part and the casing
Insulation resistance	DC250V
	20MΩ or more, Between the entire charging part and the casing
Working temperature	- 20℃～ +85℃ (no condensation)
Working environment humidity	20～80%RH
Wire specifications	φ2.8×1000mm ※ 1
	LSPSF014: gray
	LSPSF014(B): black
shell material	SUS303
Install	M10 nut, tightening torque 12N·m
Installation hole diameter processing dimensions	10 +0.5 0

※1 Output conversion, current amplification, and cable extension can be achieved through wire accessories. Please refer to P. 127 ~ 130 for details.
