Specification
| voltage | DC5~24V |
| journey | 1mm |
| Working point position [PT] | 0.15~0.4mm |
| Repeatability | ±0.002mm |
| output method | LSTSMS1A: |
| NPN normally open (ON during operation) |
| LSTSMS1B: |
| NPN normally closed (OFF during action) |
| Output current | 15mAMAX |
| Current consumption | 8mAMAX |
| working frequency | 60 times/min or less |
| Withstand voltage | AC1000V |
| 1 minute, between the entire charging part and the casing |
| Insulation resistance | DC250V |
| 20MΩ or more, between the entire charging part and the casing |
| Working temperature | With sealing rubber: |
| 10℃~60℃(no condensation) |
| Without sealing rubber: |
| - 20℃~ +85℃ (no condensation) |
| Working environment humidity | 20~95%RH |
| Wire specifications | φ2.8×1000mm gray |
| Wire specifications | LSTSMS1A: gray |
| LSTSMS1B: black |
| shell material | Glass fiber reinforced resin (black) |
| Rubber seal material | Nitrile rubber |
Note) Output conversion, current amplification, and cable extension can be achieved through wire accessories. Please refer to P.127 ~ 130 for details.
Maximum operating force
| sealing rubber | Standard | Low operating force specification |
| Button type | none | 0.5 | 0.1 |
| have | 0.5 |
|
| Contact type | none | 0.25 | 0.1 |
| have | 0.3 |
|
