voltage	DC12~24V
journey	8mm
Operating force	0.4N
Working point position [PT]	0.3~0.8mm
Return difference[MD]	0.1mm or less
Repeatability	±0.01mm
Output current	50mAMAX
leakage current	When OFF, maximum 0.5mA or less
working frequency	60 times/min or less
Withstand voltage	AC1000V
	1 minute, between the entire charging part and the casing
Insulation resistance	DC250V
	20MΩ or more, between the entire charging part and the casing
Working temperature	-20℃ ~ +85℃ (no condensation)
Working environment humidity	20~95%RH
Wire specifications	2 core φ2.8×1000mm
	LSTS92: gray
	LSTS92(B): black
Operating lever material	SUS303
shell material	Glass fiber reinforced resin (black)
Install	M3 screws, tightening torque 0.3N·m
indicator light	red
protection level	IP65

Note) Please be sure to connect the load before use.
